C4A-B packing unit 1000 pcs.
Dimensions
| General technical data | |||
|---|---|---|---|
| Material | Plastic black (B) | ||
| Screw | M4 | ||
| D | Diameter | 8 | mm |
| H | Height | 1,2 | mm |
| Name | Category | Product | Size | Language |
|---|---|---|---|---|
| Linear guideways | Assembly Instructions | Linear guideways | 5 MB | |
| Linear guideways | Project planning sheet | Linear guideways | 2 MB | |
| Linear guideways | Catalogue | Linear guideways | 7 MB | |
| CG linear guideways | Flyer | Linear guideways | 299 KB |
Principle of operation of a linear guideway
A linear guideway makes it possible to move in a linear motion with rolling elements. The use of balls and rolls between the rail and block in a linear guideway makes precise linear movements possible.
Long-time lubrication unit of a linear guideway
The long-time lubrication unit for linear guideways makes it possible to increase lubrication intervals many times over, thereby considerably reducing the number of maintenance intervals. If needed, up to two long-time lubrication unit can be installed per block.
Assembly and disassembly of cover caps
The cover caps are used to keep the mounting holes of the profile rails free of chips and dirt. In this video, we show you how to easily assemble and disassemble steel, brass or plastic cover caps.
